Mud Pump Valve & Seat

Name: Mud pump valve & seat;

Valve Body material: 20CrMnTi;

Valve Seat material: 20CrMnTi;

Cuff material: PU / NBR / HNBR;

The MAX working pressure: 35 /52 Mpa;

Valve type: API 6# / API 7# / BOMCO / 7V1 / Full Open / 3-web / 4-web / K7 / K9

More mud pump parts


Get quotes

Send RFQs, Reply quotation within 8 hrs
LONGWELL's mud pump parts catalog

  • Tel & Whatsapp

    +86 18792729070

  • Email

    longwell@longwell.ltd

Mud pump valve & seat was a part of the mud pump parts in fluid end module, it was working with mud pump liner and mud pump piston, Mud pump valve & seat used for seal and transport rig mud.

types of mud pump valve & seat

types of mud pump valve & seat



Drilling rig mud is pushed from the mud pump liner by the mud pump piston to the mud pump module, and after being opened and closed by the mud pump valve assembly, it is discharged from the mud pump module through the discharge pipeline.

API 6# mud pump valve

API 6# mud pump valve

Datasheet for API 6# mud pump valve

Valve body material
20CrMnTi
Valve Seat material
20CrMnTi
Cuff material
PU / NBR / HNBR
The MAX working pressure
35 /52 Mpa (5000/7500PSI)
Valve type
API 6# / API 7# / BOMCO / 7V1 / Full Open / 3-web / 4-web / K7 / K9
Operating temperature range
-10°C to +100°C
MOQ
6 Piece
Productivity
6000 Pieces per month
Packing
Each valve with waterproof plastic bag and carton, outside with plywood case
Payment terms
TT, 30% DP, balance before ship

Mud pump valve & seat part number

AH33001-05.17A.00, AH0000020100, AH33001-05.17A.06, AH0000020101, AH000002010200,

AH36001-05.12A.00, AH0000020300, AH000002030100, AH36001-05.12A.04, AH0000020302,

If you need more mud pump parts, please download the catelog.

1 .Packaging & delivery

Plywood case for mud pump valve and seat, the total gross weight of each pallet shall not exceed 1.5 tons, suitable for sea and railway transportation

2 .Minimum order quality

6 pieces

3 .I have more questions

Please leave a message online
